Tornado 99328 User Manual

39
SOLUTION TANK ASSEMBLY
(Ref. Drawing 30867)
ITEM QTY PART # DESCRIPTION
1 6 00851 WASHER - PLAIN 1/4”
2 6 01497 NUT - FINISHED HEX 1/4-20
3 6 01574 LOCK WASHER 1/4”
4 2 07741 WASHER - SEALING 1/4
5 3 13854 LOCK NUT, 1/4-20
6 3 15461 SCREW - SLOTTED ROUND HEAD MACHINE 1/4-20 x 1-1/4
7 1 16679 SOLUTION TANK, 25 GAL.
8 2 16680 FITTING, BARBED ELBOW
9 1 16798 MOUNTING PLATE
10 1 16799 GASKET
11 1 16800 COVER, SOLUTION TANK
12 1 16803 MOUNTING STRIP
13 6 18641 SCREW - HEX HEAD CAP 1/4-20 X 1-3/4
14 2 19096 FILTER - SOLUTION BLADDER PUMP
