Tornado 99328 User Manual

36
RECOVERY (VACUUM) TANK ASSEMBLY PARTS LIST
(Ref. Drawing 30868)
ITEM QTY PART # DESCRIPTION
1 8 00067 NUT - LOCK 5/16-18
2 4 01497 NUT - FINISHED HEX 1/4-20
3 4 01574 LOCK WASHER 1/4”
4 2 01979 SCREW-PHILLIPS ROUND HEAD MACHINE 1/4-20 X 2.00
5 12 02568 WASHER - PLAIN 5/16
6 12 03218 WASHER - PLAIN 1/4
7 1 03397 FLANGE, STAND PIPE
8 2 03419 GASKET, STAND PIPE
9 2 03493 NUT, THUMB 5/16-18
10 2 05282 NUT - HEAVY HEX JAM 5/16-18
11 2 07533 NUT - HEX LOCK 1/4-20
12 4 07741 WASHER - SEALING 1/4
13 4 07744 SCREW - HEX HEAD MACHINE 1/4-20 X 1-5/16
14 4 10260 WASHER - SEALING
15 3 10353 SCREW - SLOTTED TRUSS HEAD MACHINE 1/4-20 X 1/2
16 3 13854 LOCK NUT, 1/4-20
17 3 15181 SCREW - HEX HEAD CAP 1/4-20 X 3.00
18 1 15535 TANK DRAIN PLATE
19 2 15776 RETAINING KNOB
20 4 16031 SCREW - HEX HEAD CAP 5/16-18 X 1-1/2
21 1 16089 STOPPER, RETAINED
22 3 16091 CLAMP
23 1 16620 HOSE W/BELLOWS SECTION
24 1 16621 DRAIN BACKING PLATE
25 4 16678 GROMMET
26 1 16784 STAND-PIPE ASSEMBLY
27 4 16796 SPACER
28 1 16874 HOSE I 1/2’’ x 9’’ VINYL BLACK
29 2 17093 SET SCREW 5/16-18 X 1-3/4’ LG.
30 2 17508 NUT - FINISHED HEX 1/4-20
31 3 17608 SPACER, VAC MOTOR
32 6 17610 WASHER - ISOLATOR
33 1 17646 GASKET, DRAIN PLATE
34 1 17647 GASKET, BACKING PLATE
35 1 17700 FLAT HEAD CAP SCREW 5/16-18 X 5/8” LG.
36 1 18563 DRAIN HOSE, NOZZEL
37 1 18771 FLOAT
38 1 18772 FLOAT CAGE
39 1 18832 HOSE I 1/2’’ x 12’’ VINYL GREY
40 1 18965 ASSEMBLY, FLOAT COVER
41 1 19127 TANK RECOVERY 24’’-28’’
42 1 30776 COVER, MOTOR
43 1 31073 MOTOR, VAC. 36VDC
44 1 31183 WELDMENT, MOTOR MOUNT
45 1 31230 COVER ASS’Y
