Tornado 99328 User Manual

48
COVER ASSEMBLY PARTS LIST
(Ref. Drawing 31186)
ITEM QTY PART # DESCRIPTION
1 2 00600 SCREW – SLOTTED ROUND HEAD MACHINE #8-32 X ¾
2 2 02956 NUT – HEX LOCK (KEPS) #8-32
3 8 04735 SCREW – PHILLIPS TRUSS HEAD MACHINE #10-24 X 3/4
4 8 10892 NUT – HEX LOCK
5 1 15640 WARNING LIGHT
6 4 19945 SCREW – PHILLIPS TRUSS HEAD MACHINE ¼-20 X 5/8”
7 1 30767 COVER, TOP
8 1 30774 HINGE 21” LONG
9 1 30775 PLATE, HINGE
10 1 31082 TOP-COVER BRACKET

Tornado 99328 Specifications

General

Brand	Tornado
Model	99328
Category	Floor Machine
Language	English
