7
TECHNICAL DESCRIPTION U/M BD 20/11
Cleaning width mm/in 500/20
Squeegee width mm/in 790/31
Working capacity sqm/h/sqft/h 1750/18,837
Brush diameter mm/in 508/20
Brush rpm rpm 182
Pressure on the brush kg/lbs 30/66 max
Brush motor W/A 600/25
Type of drive Semi-automatic
Maximum gradient 2%
Suction motor W/A 570/24
Suction vacuum mbar\in water lift 120/48
Solution tank l/gal 40/11
Recovery tank l/gal 45/12
Machine length mm/in 1205/48
Machine height mm/in 1053/42
Machine width (without squeegee) mm/in 535/21
Capacity of the batteries V/Ah5h 24/110
Weight of the batteries kg/lbs 74/163
Compartment of the batteries mm/in 342x350x300 /13.5x13.7x12
Weight of the machine (empty and without batteries) kg/lbs 85/187
Acoustic pressure level (in conformity with IEC 704/1) dB(A) 67.6
Class III
Protection level IP X3
Tension V 24
O P T I O N A L A C C E S S O R I E S
Brush motor overload protection device
Solution tank drain
Solenoid Valve
Switch with key
Incorporated battery charger
Solution Saving System Assembly (3S)
