InstallingtheCEHoodLock
Partsneededforthisprocedure:
1Hoodlock,seal,andjamnut
1Washer
Procedure
1.Unlatchandraisethehood.
2.Removetherubbergrommetfromtheholein
theleftsideofthehood(Figure35).
g004143
Figure35
1.Rubbergrommet
3.Ensurethatthesealisassembledtothehood
lock(Figure36).
g375326
Figure36
1.Hoodlatch
3.Seal
2.Nut4.Washer
4.Removethenutfromthelock.
5.Outsidethehood,insertthehookendofthe
latchthroughtheholeinthehood.
Note:Thesealisalignedtotheoutsideofthe
hood.
6.Insidethehood,Securethelocktothehood
withthewasherandnut.
7.Closethehood,andusetheenclosedhood-latch
keytocheckthatthehookofthelockengages
theframecatchwhenlocked.
