Toro 03676 - Setting the Reel Speed

g375696
Figure54
1.Switch2.Lift-armsensingdevice
4.Adjustthelift-armswitchasfollows:
•Toincreasethelift-armturnaroundheight,
movetheswitchdown.
•Todecreasethelift-armturnaroundheight,
movetheswitchup.
5.Tightenthejamnut.
SettingtheReelSpeed
Toachieveaconsistent,highqualityofcutandauniformaftercutappearance,itisimportantthatyousetthe
reelspeedtothepropersetting.Adjustthereelspeedasfollows:
1.IntheInfoCenter,underthesettingsmenu,enterthebladecount,mowspeedandHOCtocalculate
theproperreelspeed.
2.Iffurtheradjustmentsarerequired,inthesettingsmenu,scrolldowntotheFReelRPM,RReelRPM,or
both.
3.Presstherightbuttontochangethereelspeedvalue.Asthespeedsettingischanged,thedisplaywill
continuetoshowthecalculatedreelspeedbasedonbladecount,mowspeedandHOC,butthenew
valuewillalsobedisplayed.
Note:Thereelspeedmayneedtobeincreasedordecreasedtocompensateforvaryingturfconditions.
g031995
Figure55
5inch(127mm)ReelSpeedChart
34
