ProductOverview
g216864
Figure40
1.Enginehood
5.Seatadjustments
2.Operator'sseat
6.Frontcuttingunits
3.Controlarm
7.Rearcuttingunits
4.Steeringwheel
Controls
TractionPedal
Thetractionpedal(Figure41)controlstheforward
andreverseoperation.Pressthetopofthepedalto
movethemachineforwardandthebottomtomove
themachinebackward.Groundspeeddependson
howfaryoupressthepedal.Fornoload,maximum
groundspeed,fullypressthepedalwhilethethrottle
isintheFASTposition.
Tostopthemachine,reducefootpressureonthe
tractionpedalandallowittoreturntothecenter
position.
g003955
Figure41
1.Tractionpedal4.Brakepedal
2.Mow/transportlever
5.Parkingbrake
3.Mow-speedlimiterand
spacers
6.Tiltsteeringpedal
Mow/TransportLever
Usethemow/transportlever(Figure41)toputthe
machineintoMOWmodeorTRANSPORTmode.Push
theleverforwardtoselecttheMOWmode,and
backwardtoselecttheTRANSPORTmode.
Note:Thecuttingunitscannotbeloweredwhenthe
mow/transportleverisintheTRANSPORTposition.
Mow-SpeedLimiter
Whenthemow-speedlimiter(Figure41)isipped
up/forwarditlimitsthemowspeedandallowthe
cuttingunitstobeengaged.Eachspaceradjusts
themowingspeedby0.8km/h(0.5mph).Themore
spacersthereareonthetopofthebolt,theslowerthe
machinegoes.Flipthemowspeedlimiterbackward
toallowmaximumtransportspeed.
BrakePedal
Pressthebrakepedal(Figure41)tostopthemachine.
ParkingBrake
Toengagetheparkingbrake,(Figure41)pushdown
onthebrakepedalandpressthetopforwardtolatch
it.Toreleasetheparkingbrake,pressthebrakepedal
untiltheparking-brakelatchretracts.
