Toro 03676 - Seat Controls

SeatControls
g003954
Figure45
1.Weightgauge3.Height-adjustingknob
2.Weight-adjustingknob4.Adjustinglever
Seat-PositionLever
Pulltheseat-positionlever(Figure45)tomovethe
seatforwardandrearward.Releasethelevertolock
theseatposition.
Weight-AdjustingKnob
Rotatetheweight-adjustingknobuntilyourweightis
displayedinthewindowoftheweightgauge.
Height-AdjustingKnob
Rotatetheheight-adjustingknobtochangetheheight
oftheseat.
UsingtheInfoCenterLCDDisplay
TheInfoCenterLCDdisplayshowsinformationabout
yourmachinesuchastheoperatingstatus,various
diagnosticsandotherinformationaboutthemachine
(Figure46)Thereisasplashscreenandmain
informationscreenoftheInfoCenter.Youcanswitch
betweenthesplashscreenandmaininformation
screen,atanytime,bypressinganyoftheInfoCenter
buttonsandthenselectingtheappropriatedirectional
arrow.
g020650
Figure46
1.Indicatorlight3.Middlebutton
2.Rightbutton
4.Leftbutton
•LeftButton,MenuAccess/BackButton—Press
thisbuttontoaccesstheInfoCentermenus.
Youcanuseittobackoutofanymenuyouare
currentlyusing.
•MiddleButton—Pressthisbuttontoscrolldown
menus.
•RightButton—Pressthisbuttontoopenamenu
wherearightarrowindicatesadditionalcontent.
Note:Thepurposeofeachbuttonmaychange
dependingonwhatisrequiredatthetime.Each
buttonislabeledwithanicondisplayingitscurrent
function.
InfoCenterIconDescription
SERVICEDUE
Indicateswhenscheduledservice
shouldbeperformed
Hourmeter
Infoicon
Fast
24
