lledthereservoirwithanalternativeuid,
changethehydraulicuid.
Iftheuidbecomescontaminated,contactyourT oro
Distributorbecausethesystemmustbeushed.
Contaminateduidlooksmilkyorblackwhen
comparedtocleanuid.
1.Preparethemachineformaintenance;referto
PreparingforMaintenance(page41).
2.Placealargedrainpanunderthestraighttting
(Figure116)ofthehydraulictank;referto
HydraulicFluidCapacity(page64).
g377036
Figure116
1.Straighttting(hydraulic
tank)
3.Returnlter
2.Hose(casedrain)
3.Disconnectthecase-drainhosefromthestraight
tting,andallowthetanktodrain.
4.Whenhydraulicuidstopsdrainingfromthe
tank,installthedrainhose.
5.Fillthetankwiththespeciedhydraulicuid;
refertoHydraulicFluidSpecications(page62)
andHydraulicFluidCapacity(page64).
Important:Useonlythehydraulicuids
specied.Otheruidscouldcausesystem
damage.
6.Installthetankcap.
7.Starttheengine,anduseallthehydraulic
controlstodistributehydraulicuidthroughout
thesystem.
8.Checkforhydraulic-uidleaks;refertoChecking
forLeaks(page64).
9.Checkthelevel;refertoCheckingthe
Hydraulic-FluidLevel(page62)
CuttingUnitSystem
Maintenance
BladeSafety
Awornordamagedbladeorbedknifecanbreak,and
apiececouldbethrowntowardyouorbystanders,
resultinginseriouspersonalinjuryordeath.
•Inspectthebladesandbedknivesperiodicallyfor
excessivewearordamage.
•Usecarewhencheckingtheblades.Weargloves
andusecautionwhenservicingthem.Only
replaceorbacklapthebladesandbedknives;
neverstraightenorweldthem.
•Onmachineswithmultiplecuttingunits,takecare
whenrotatingacuttingunit;itcancausethereels
intheothercuttingunitstorotate.
Checkingthe
Reel-to-BedknifeContact
ServiceInterval:Beforeeachuseordaily
Checkthereel-to-bedknifecontact,regardlessof
whetherthequalityofcuthadpreviouslybeen
acceptable.Theremustbelightcontactacrossthefull
lengthofthereelandthebedknife(refertoAdjusting
theReeltoBedknifeinthecuttingunitOperator's
Manual).
BacklappingtheCutting
Units
WARNING
Contactwiththecuttingunitsorothermoving
partscanresultinpersonalinjury.
•Keepyourngers,hands,andclothing
awayfromthecuttingunitsandother
movingparts.
•Neverattempttoturnthecuttingunitsby
handorfootwhiletheengineisrunning.
Note:Additionalinstructionsandprocedureson
backlappingareavailableintheT oroReelMower
Basics(withsharpeningguidelines),Form09168SL.
PreparingtheMachine
1.Preparethemachineformaintenance;referto
PreparingforMaintenance(page41).
2.PresstheEnable/DisableswitchtoDISABLE
position.
