Toro 03676 - Replacing the Telematic Fuse; Replacing the TEC Controller Fuse

g375761
Figure98
1.Fuseblock
2.Fusedecal(insidethe
control-armcover)
4.Assemblethecontrol-armcovertothecontrol
arm,andsecurethecoverwiththe2latches.
ReplacingtheTelematic
Fuse
1.Preparethemachineformaintenance;referto
PreparingforMaintenance(page41).
2.Unlatchandtiltseat;refertoTiltingtheSeat
(page42).
3.Removethecapfromthein-linefuseholder
labeled10AFUSETELEMATICPWR(Figure99).
g378242
Figure99
1.Cap3.Fuseholder(labeled10A
FUSETELEMATICPWR)
2.Fuse
4.Removethefusefromthefuseholder.
5.Insertafuseofthesametypeandamperage.
6.Assemblethecapontothein-linefuseholder.
7.Lowerandlatchtheseat;refertoLoweringthe
Seat(page42).
ReplacingtheTEC
ControllerFuse
1.Preparethemachineformaintenance;referto
PreparingforMaintenance(page41).
2.Openthehood;refertoOpeningtheHood(page
41).
3.Locatethein-linefuseholderthatisinboardof
thebattery(Figure100).
54
