Greensmaster Flex 21Groomer (Model 04201) (Rev. B) Page 8 – 2
Specifications
MOUNTING: The groomer is mounted to the mower reel
bearing housings and frame.
REEL CONSTRUCTION: 2.375 inch (6 cm) diameter,
41 steel blades with 1/2–inch blade spacing. Spacing is
also adjustable to 1/4 and 3/4–inch (6.4 and 19.1 mm)
spacing by varying the number of blades and spacers.
GROOMING PENETRATION: Maximum of 0.125 inch
(3.2 mm).
HEIGHT ADJUSTMENT KNOB: Allows a 0.003 inch
(0.08 mm) increment of height adjustment for each click
of the adjuster.
QUICK UP–DOWN FEATURE: Allows groomer reel to
be raised above the height/depth adjustment for no
grooming while cutting or transport.
WIDTH–OF–GROOMING: 19 inches (48.3 cm).
