GovernorAssemblyRemoval(continued)
2.Turnthemotorupsidedown.
3.Removethe7(10mm)boltssecuringthesumpcovertothecrankcase.
Figure298
4.Usingasoftbasehammer,tapthesumpcovertoremovefromthecrankcase.
Figure299
5.Removethesumpcoverfromthecrankcase.
EngineLowerEnd:ServiceandRepairs
Page9–6
1P65F-2ServiceManual
3429-270RevA
