Toro 21464 - Page 123

AWDFrontTransmissionRemoval(continued)
g360056
Figure149
13.Removethebeltfromthetransmission.
14.Removethetransmissionfromthechassis.
15.Inspectthebeltforwear.Replaceifnecessary.
16.Inspectthebladedriverpulleyforwear.Replaceifnecessary.
17.Inspectthetransmissionpulleyforwear.Replacethetransmissionifwearon
thetransmissionpulleyexists.
AWDFrontTransmissionInstallation
1.Installthetransmissionintothechassis.
2.Installthebeltontothetransmissionpulley.
3.Installthetransmissionbracketontothetransmission,securewith3(#10–14)
screws.T orquethescrewsto2.82±0.56N•m(25±5in-lbs).
22InchAWD/RWDSteelDeckWalkPowerMowerService
Manual
Page7–19
DriveSystem:ServiceandRepairs
3445-579RevA
