Toro 21472 - RWD Transmission Replacement

RearWheelRemoval(continued)
7.Removethepiniongear,thrustwasher,andrearpivotfromtheLH
transmissionaxleshaft.RepeatontheRHsideoftheunit.
RearWheelInstallation
1.Installtherearpivot,thrustwasher,andpiniongearontotheLHtransmission
axleshaft.RepeatontheRHsideoftheunit.
2.InstallthesnapringontotheLHtransmissionaxleshaft.RepeatontheRH
sideoftheunit.
3.InstallthegearcoverandwheeltotheLHpivotarm,securewiththe(3/8–16
inch)wheelbolt.Torquetheboltto35±1.69N•m(315±15in-lb).Repeat
ontheRHsideoftheunit.
g352317
Figure137
4.Modelsequippedwithelectricstartonly,connectthebatterybyinstalling
thepositivecablerst,thenthenegativecabletothebattery.Installthefoam
padandbatterycover.Securethebatterycoverwith2(M4.2x2.0)screws.
Torquethescrewsto2.26±0.34N•m(20±3in-lbs).
5.Modelsequippedwiththe60vpowerhead,installtheharnesstothe
powerhead.
RWDTransmissionReplacement
RWDTransmissionRemoval
1.Parkthemachineonalevelsurface,stoptheengineandwaitforallmoving
partstostop.
2.Modelsequippedwiththe60vpowerhead,removetheharnessfrom
powerhead.
3.Modelsequippedwithelectricstartonly,removethe2(M4.2x2.0)
screwssecuringthebatterycover.Removethebatterycoverandfoampad.
Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
4.Removethegrassbaggerassemblyifattached.
5.Removethetractioncable.RWDTractionCableRemoval(page5–8)
