AWDFrontTransmissionInstallation(continued)
g360056
Figure150
4.Installthebeltguideguardontothedeck,securewith2(1/4–10inch)screws.
Torquethescrewsto2.82±0.56N•m(25±5in-lbs).
g352577
Figure151
5.Installthebladeontotheenginecrank.RefertotheproductOperator’s
Manualforthebladeinstallationprocedures.
6.Installthecablereturnspringtothedeckandthefronttractioncontrolcable
anchortothetransmissionmount.
