Engine/PowerheadInstallation(continued)
2.Installthe3(3/8–16x1.0inch)screwssecuringtheengine/powerheadtothe
deck.T orquethescrewsto45.19–56.49N•m(400–500in-lbs).
g352013
Figure8
3.Installthe(1/4x1.33inch)shoulderscrewsecuringthebottomintakecover
tothedeck.Torquethescrewto3.39±0.339N•m(30±3in-lbs).
g352012
Figure9
4.Installthebladedriverontothecrank.
22InchAWD/RWDSteelDeckWalkPowerMowerService
Manual
Page4–7
PowerSource:ServiceandRepairs
3445-579RevA
