RWDPERSONALPACE®HandleAssemblyInstallation(continued)
g352894
Figure58
11.Usinga3/8inchwrench,installthecurvedwasherandlocknutsecuring
thecableanchortothecurvedhandle.Torquethenutto4.52±0.56N•
m(40±5in-lbs).
g352893
Figure59
12.InstallthebailontothePERSONALPACE®handleassembly.
Controls:ServiceandRepairs
Page5–28
22InchAWD/RWDSteelDeckWalkPower
MowerServiceManual
3445-579RevA
