AWDPERSONALPACE®HandleAssemblyInstallation(continued)
g353060
Figure72
1.HandlePins
8.Installthe10(M4.2x2.0)screwssecuringtheLHandRHbottomhandles
andupperPERSONALPACE®handletothecurvedhandle.T orquethe
screwsto2.26±0.34N•m(20±3in-lbs).
g353048
Figure73
9.Installthefrontandreartractioncablestothecableyolk.
10.Installthecableclamptothecableanchor,securewiththe(1/4–20inch)
carriagescrew,washer,andnut.T orquethenutto4.52±0.56N•m(40±
5in-lbs).
11.InstallthebailontothePERSONALPACE®handleassembly.
22InchAWD/RWDSteelDeckWalkPowerMowerService
Manual
Page5–35
Controls:ServiceandRepairs
3445-579RevA
