CurvedHandleRemoval(ElectricStartModelsOnly)(continued)
2.Removethegrassbaggerassemblyifattached.
3.Modelsequippedwiththe60vpowerhead,removetheharnessfrom
powerhead.
4.Removethe2(M4.2x2.0)screwssecuringthebatterycover.Removethe
batterycoverandfoampad.Disconnectthebatterybyremovingthenegative
cablerst,thenthepositivecablefromthebattery.
5.Removethe2cabletiessecuringtheelectricstarterwireharnesstothe
curvedhandle.
g353634
Figure83
6.Removethecableguidefromthecurvedhandle.
7.Loosenthe(7/16inch)screwandremovecapturedNIlocknutsecuringthe
cableguideandelectricstartertothecurvedhandle.Removetheelectric
starterfromthecurvedhandle.
8.RemovetheRWDPERSONALPACE®handle.RWDPERSONALPACE®
AssemblyHandleRemoval(page5–20)
9.Removethelocknutsecuringtheropeguidetothecurvedhandle.
