RWDFrontHeight-of-CutInstallation(continued)
g352391
Figure99
2.Installthemountbushing,springarm,andthefrontpivotarmtotheLH
height-of-cutplateandsecurewiththe(5/16–18inch)screw,atwasher,
andnut.T orquethenutsto19.2±3.39N•m(170±30in-lb).Repeaton
theRHsideoftheunit.
g352409
Figure100
3.Installthefrontnon-drivewheels.RWDFrontWheelInstallation(page7–6)
4.Modelsequippedwithelectricstartonly,connectthebatterybyinstalling
thepositivecablerst,thenthenegativecabletothebattery.Installthefoam
padandbatterycover.Securethebatterycoverwith2(M4.2x2.0)screws.
Torquethescrewsto2.26±0.34N•m(20±3in-lbs).
5.Modelsequippedwiththe60vpowerhead,installtheharnesstothe
powerhead.
Deck:ServiceandRepairs
