5.Usinga1/2inchdriveratchet,turnthetensioning
screwuntilthetrackdeectionis13mm(1/2
inch)asshowninFigure56.
Note:Turningthescrewcounter-clockwise
tightensthetrack;turningthescrewclockwise
loosensthetrack.
6.Aligntheclosestnotchinthetensionscrewto
thelocking-boltholeandsecurethescrewwith
thelockingboltandnut(Figure57).
7.Repeattheprocedurefortheothertrack.
8.Drivethemachine,thenparkthemachineona
levelsurface,engagetheparkingbrake,shutoff
theengine,andremovethekey.
9.Verifythatthetrackdeectionis13mm(1/2
inch)asshowninFigure56.Adjustifnecessary.
MachineswithWideTracks
Verifythatthetensionblockisalignedwiththegreen
guideonthedecalorthattheblockis1.3cm(1/2inch)
awayfromtherearofthetensiontubeslot(Figure58).
g203962
Figure58
1.Greenguideondecal
2.Tensionblock
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Removethelockingbolt,spacer,andnut(Figure
59).
g029758
Figure59
1.Tensiontube3.Tensioningscrew
2.Lockingbolt
4.Usinga1/2inchdriveratchet,turnthetensioning
screwuntilthetensionblockalignswiththe
greenguideonthedecaloris1.3cm(1/2inch)
awayfromtherearofthetensiontubeslot
(Figure58).
Note:Turningthescrewcounter-clockwise
tightensthetrack;turningthescrewclockwise
loosensthetrack.
5.Aligntheclosestnotchinthetensionscrewto
thelocking-boltholeandsecurethescrewwith
thelockingboltandnut(Figure59).
6.Repeattheprocedurefortheothertrack.
7.Drivethemachine,thenparkthemachineona
levelsurface,engagetheparkingbrake,shutoff
theengine,andremovethekey.
8.Verifythatthetensionblockalignswiththe
greenguideofthedecaloris1.3cm(1/2inch)
awayfromtherearofthetensiontubeforboth
tracks(Figure58).Adjustifnecessary.
