g217640
Figure66
1.Nut
3.Outerfrontwheel
2.Washer4.Track
8.Removethetrack(Figure66).
9.Pullthe2largewashersoutoftheouterwheels,
1oneachsideofeachwheel(Figure66).
10.Cleantheoldgreaseanddirtoutofthearea
betweenwherethewasherswereinstalledand
thebearingsinsidethewheels,thenllthisarea
oneachsideofeachwheelwithgrease.
11.Installthelargewashersonthewheelsoverthe
grease.
12.Installthenewtrack.(Figure66).
Note:Ensurethatthelugsinthetrackt
betweenthespacersinthemiddleofthedrive
sprocket.
13.Installtheouterfrontwheelandsecureitwith
thenutremovedpreviously(Figure66).
14.Torquethenutto300ft-lb(407N∙m).
15.Turnthetensioningscrewcounter-clockwise
untilthetensioningscrewbottomsout(Figure
67).
g203963
Figure67
1.Tensionnut2.Tensionscrew
16.Aligntheclosestnotchinthetensionscrewto
thelockingboltholeandsecurethescrewwith
thelockingboltandnut.
17.Torquetherearboltto108to122N∙m(80to
90ft-lb).
18.Lowerthemachinetotheground.
19.Repeattheproceduretoreplacetheothertrack.
20.Drivethemachine,thenparkthemachineona
levelsurface,engagetheparkingbrake,shutoff
theengine,andremovethekey.
21.Verifythatthetensionblockisbottomedout.
Note:Thetracktensionloosensaftersome
use.
22.Adjustthetracktensionsothatthetensionblock
alignswiththegreenguideonthedecaloris1.3
cm(1/2inch)awayfromtherearofthetension
tubeslot;refertoAdjustingtheTrackT ension
(page40).
