WARNING
Batteryterminalsormetaltoolscouldshort
againstmetaltractorcomponentscausing
sparks.Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,
donotallowthebatteryterminalstotouch
anymetalpartsofthetractor.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsof
thetractor.
7.Installthebatteryintothemachineandsecureit.
Important:Thebatterymustnotbeabletomove
orwigglewhenpushed.
8.First,installthepositivecable(red)tothepositive(+)
terminalandthenthenegativecable(black)tothe
negative(-)terminalofthebattery.Slidetherubber
bootoverthepositiveterminaltopreventapossible
shortfromoccurring.
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcablescausingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
WARNING
Connectingcablestothewrongpostcould
damagetheelectricalsystemandresultin
personalinjury.
Note:Ensurethatthebatterycablesareroutedaway
fromanysharpedgesormovingparts.
3
InstallingtheMower
Deck/PolarTrac
Partsneededforthisprocedure:
1
MowerDeckorPolarTracKit(soldseparately)
InstallingaMowerDeckKit
1.Removethetractionunitfromtheshippingpallet.
2.Placeajackstandundereachwheelmotorandaoor
jackundertherearbumper(
Figure5),orsuspendfrom
aoverheadhoist.
Figure5
1.Rearbumper2.Floorjack
3.Installthesummerdrivetires(Figure6)
Figure6
1.Summerdrivetire
4.Rollthesummerdeckandframeintopositionand
installtheve3/4inchbolts,washersandnutsthat
connectthedeckframetotherearframe(Figure7).
11
