Figure35
1.Pressurehose2.Returnhose
27.Removethecapandplugthecabwireharness
connectorintotheharnessontherearframemount
(Figure36).
Figure36
1.Cabwireharness
connector
2.Harnessconnectoronthe
rearframemount
28.Startthemachine.Runtheliftarmupanddownand
checkforhydraulicleaks.Checktheantifreezelevel
andreplenishasrequired.
ProductOverview
Controls
Becomefamiliarwithallthecontrolsbeforeyoustartthe
engineandoperatethemachine(Figure37).
Figure37
TractorControlPanel
1.Ignitionswitch
5.Oilpressurewarninglight
2.Enginecoolant
temperaturewarning
light
6.Chargeindicatorlight
3.Glowpluglight
7.Throttlelever
4.Powertakeoff(PTO)
Switch
8.Hourmeter
MotionControlLevers
Themotioncontrolleverscontroltheforwardandrearward
motionsaswellastheturningofthemachine.
ParkingBrakeLever
Whenevertheengineisshutoff,engagetheparkingbraketo
preventaccidentalmovementofthemachine.Toengagethe
parkingbrake,pulltheparkingbrakeleverrearwardandup
(Figure38).Toreleasetheparkingbrake,pushtheparking
brakeleverforwardanddown.
