Toro 30413 - Product Overview; Controls

ProductOverview
Figure2
1.Tractionpedal
6.Chargeindicator
2.Brakepedals7.Engineoilpressure
warninglight
3.Pedallockinglatch8.Enginecoolant
temperaturewarning
light
4.Tiltsteeringlever
9.Glowplugindicatorlight
5.Parkingbrakelatch10.Temperaturegauge
Controls
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
Thismachineproducessoundlevelsinexcess
of85dBAattheoperatorsearandcancause
hearinglossthroughextendedperiodsof
exposure.
Wearhearingprotectionwhenoperatingthis
machine.
TractionPedal
Thetractionpedal(Figure2)controlsforwardand
reverseoperation.Pressthetopofthepedaltomove
forwardandthebottomtomovebackward.Ground
speeddependsonhowfaryoupressthepedal.Forno
load,maximumgroundspeed,fullypressthepedalwhile
thethrottleisinFast.
Tostop,reduceyourfootpressureonthetractionpedal
andallowittoreturntothecenterposition.
BrakePedals
Twofootpedals(Figure2)operateindividualwheel
brakesforturningassistance,parking,andtoaidin
obtainingbettersidehilltraction.Alatchconnectsthe
pedalsforparkingbrakeoperationandtransport.
PedalLockingLatch
Thepedallockinglatch(Figure2)connectsthepedals
togethertoengagetheparkingbrake.
TiltSteeringLever
Pressthelever(Figure2)downtotiltthesteeringwheel
tothedesiredposition.Thenreleasethelevertolock
theadjustment.
ParkingBrakeLatch
Aknobontheleftsideoftheconsoleactuatesthe
parkingbrakelock(Figure2).Toengagetheparking
brake,connectthepedalswiththelockinglatch,push
downonbothpedals,andpulltheparkingbrakelatch
out.Toreleasetheparkingbrake,pressbothpedalsuntil
theparkingbrakelatchretracts.
ChargeIndicator
Thechargeindicator(Figure2)illuminateswhenthe
systemchargingcircuitmalfunctions.
EngineOilPressureWarningLight
Thelight(Figure2)illuminateswhentheengineoil
pressureisdangerouslylow.
EngineCoolantTemperatureWarning
Light
Thelight(Figure2)illuminatesandtheengineshuts
downwhencoolantreachesanexcessivelyhigh
temperature.
GlowPlugIndicatorLight
Whenlit,theglowplugindicatorlight(Figure2)
indicatesthattheglowplugsareon.
