Important:Neverattempttocleanthesafety
lter(Figure49).Replacethesafetylterwitha
newoneaftereverythreeprimarylterservices.
Figure49
1.Aircleanersafetylter
4.Cleanthedirtejectionportlocatedintheremovable
cover.Removetherubberoutletvalvefromthe
cover,cleanthecavityandreplacetheoutletvalve.
5.Installthecoverorientingtherubberoutletvalvein
adownwardposition-betweenapproximately5:00
to7:00whenviewedfromtheend.
6.Resettheindicator(Figure47)ifitshowsred.
ServicingtheEngineOiland
Filter
ServiceInterval:Aftertherst50hours
Every150hours
Changetheoilandlterinitiallyaftertherst50hours
ofoperation;thereafterchangetheoilandlterevery
150hours.
1.Removeeitherdrainplug(Figure50)andlettheoil
owintoadrainpan.Whentheoilstops,installthe
drainplug.
Figure50
1.Engineoildrainplug
2.Removetheoillter(Figure51).Applyalightcoat
ofcleanoiltothenewltersealbeforescrewingit
on.Donotovertighten.
Figure51
1.Engineoillter
3.Addoiltothecrankcase;refertoCheckingthe
EngineOil.
38
