levelisuptothebottomoftheplanetaryandbrake
housingcheckholes.Capacityisapproximately16
oz.(0.5l).
9.Installtheplugs.
10.Repeattheprocedureontheoppositegearassembly.
Figure59
1.Brakehousing
3.Checkplug
2.Drainplug
ChangingtheRearAxle
Lubricant
ServiceInterval:Aftertherst200hours
Every800hours
Changetheoilinitiallyaftertherst200hoursof
operationandevery800hoursofoperationthereafter.
1.Positionthemachineonalevelsurface.
2.Cleantheareaaroundthe3drainplugs;1oneach
endand1inthecenter(Figure60).
3.Removethecheckplugstoeaseindrainingoftheoil.
4.Removethedrainplugsandallowtheoiltodrain
intothepans.
Figure60
1.Drainpluglocation
5.Cleantheareaaroundthedrainplugonthebottom
ofthegearbox(Figure61).
6.Removethedrainplugfromthegearboxandallow
theoiltodrainintoapan.Removethellplugto
easeindrainingoftheoil.
Figure61
1.Drainplug
7.Addenoughoiltobringtheleveluptothebottom
ofthecheckplugholes;refertoCheckingtheRear
AxleLubricant,andCheckingtheRearAxleGear
BoxLubricant.
8.Installtheplugs.
