Toro 30413 - Mower Maintenance; Pivoting (Tilting) the Front Cutting Unit Upright

Figure73
1.Flowcontrolvalve
MowerMaintenance
Pivoting(Tilting)theFront
CuttingUnitUpright
Note:Althoughnotneededfornormalmaintenance
procedures,thefrontcuttingunitcanbepivoted(tilted)
toanuprightposition.Shouldyoudesiretotiltthe
cuttingunit,proceedasfollows:
1.Raisethecenterandwingcuttingunitsslightlyoffof
theoor,settheparkingbrake,andstoptheengine.
Removetheignitionkey.
2.Removethehairpincottersecuringdamperstolift
arms(Figure74).Pivotdampertowarddeckhousing.
Figure74
1.Damper2.Hairpincotter
3.Removethehairpincotterandclevispinsecuring
theheight-of-cutchainstotherearofthecutting
unit(Figure75).
Figure75
1.Height-of-cutchain
4.Starttheengineandslowlyraisethecentercutting
unit.
5.Slowlyraiseeachwingcuttinguntilthecenterof
gravityshiftsandthedeckstartstorotateintothe
uprightposition.Stoptheengineandremovethe
ignitionkey.
50
