Toro 30413 - Correcting Cutting Unit Mismatch

Figure84
1.CuttingEdge3.Wear/slotForming
2.CurvedArea4.Crack
3.Examinethecuttingedgesofalloftheblades.
Sharpenthecuttingedgesiftheyaredullornicked.
Sharpenonlythetopofthecuttingedgeand
maintaintheoriginalcuttingangletomakesure
ofsharpness(Figure85).Thebladewillremain
balancedifthesameamountofmetalisremoved
frombothcuttingedges.
Ifthebladeisallowedtowear,aslotwillform
betweenthesailandatpartoftheblade
(Figure84).Eventuallyapieceoftheblade
maybreakoffandbethrownfromunderthe
housing,possiblyresultinginseriousinjuryto
youorbystanders.
•Inspectthebladeperiodicallyforwearor
damage.
•Nevertrytostraightenabladethatisbent
orweldabrokenorcrackedblade.
•Replaceawornordamagedblade.
Figure85
1.Sharpenatoriginalangle
Note:Removethebladesandsharpenthemona
grinder.Aftersharpeningthecuttingedges,install
thebladewiththeanti-scalpcupandbladebolt;refer
toRemovingandInstallingtheCutterBlade(s).
CorrectingCuttingUnit
Mismatch
Ifthereismismatchbetweentheblades,onasingle
cuttingunit,thegrasswillappearstreakedwhenitiscut.
Thisproblemcanbecorrectedbymakingsurethatthe
bladesarestraightandallofthebladesarecuttingon
thesameplane.
1.Usinga3foot(1meter)longcarpenterslevel,nd
alevelsurfaceontheshopoor.
2.Raisetheheight-of-cuttothehighestposition;refer
toAdjustingtheHeight-Of-Cut.
3.Lowerthecuttingunitontotheatsurface.Remove
thecoversfromthetopofthecuttingunit.
4.Loosentheangenutsecuringtheidlerpulleyto
releasethebelttension.
5.Rotatethebladesuntiltheendsfaceforwardand
backward.Measurefromtheoortothefronttipof
thecuttingedge.Rememberthisdimension.Then
rotatethesamebladesothattheoppositeendis
forward,andmeasureagain.Thedifferencebetween
55
