Toro 30651 - Throttle Control; Adjustable Steering Column

WARNING
Takecarewhenusingtheemergencybraking.
Remainseatedandholdontothesteeringwheel
topreventejectionfromthemowercausedbythe
frontwheelbrakesbeingappliedsuddenlywhen
travelling.
ThrottleControl
Operatethethrottlecontrolinaforwarddirectionto
increasetheenginespeed.Operatethethrottlecontrol
inarearwarddirectiontoreduceenginespeed(Figure7).
Note:Theenginespeeddictatesthespeedoftheother
functions,i.e.travel,cuttingbladerotationspeedand
cuttingunitliftspeed.
1
G018034
Figure7
1.Throttlecontrol
Travel
Forwardtravel:Depresstheforwardtravelpedalto
increaseforwardtravelspeed.Releasethepedalto
reducespeed(
Figure8).
Reversetravel:Depressthereversetravelpedalto
increasereversetravelspeed.Releasethepedaltoreduce
speed(Figure8).
Stop(Neutral):Releasetheforwardorreversetravel
pedal.
g014420
1 2
Figure8
1.Reversetravelpedal2.Forwardtravelpedal
CuttingUnitDriveSwitch
AlwaysputthecuttingunitdriveswitchintheOff
positionwhentravellingbetweenworkareas.
AdjustableSteeringColumn
WARNING
Neveroperatethemowerwithoutrstcheckingthat
thesteeringcolumnadjustermechanismisingood
workingorderandthat,onceadjustedandlocked,
thesteeringwheelremainssecurelyinposition.
Adjustmentofthesteeringwheelandsteeringcolumn
shouldonlybecarriedoutwhenthemowerisata
standstillwiththeparkingbrakeengaged.
1.Totiltthesteeringwheel,pressthefootpedaldown.
2.Positionthesteeringtowertothemostcomfortable
positionandreleasethepedal(
Figure9).
G014549
Figure9
13
