Toro 30651 - Check the Torque of the Wheel Nuts; Operator Platform Latching Mechanism; Operator Presence Control

2
1
G014570
3
Figure24
1.Hydraulictankcap
3.Sightlevelgauge
2.Oiltank
4.Removethecapandllthetanktotheuppermark
onthesightlevelgauge.Donotoverll.
5.Installthecapontothetank.
ChecktheTorqueoftheWheel
Nuts
ServiceInterval:Beforeeachuseordaily
Torquethewheelnutsto148ft-lb(200N-m)forthe
frontaxle,and40ft-lb(54N-m)fortherearaxle.
WARNING
Failuretomaintainpropertorqueofthewheelnuts
couldresultinpersonalinjury.
OperatorPlatformLatching
Mechanism
Donotoperatethemowerwithoutrstcheckingthat
theoperatorplatformlatchingmechanismisfully
engagedandingoodworkingorder.
WARNING
Neveroperatethemowerwithoutrstchecking
thattheoperatorplatformlatchingmechanismis
fullyengagedandingoodworkingorder.
ReleasingthePlatform
1.Movethelockinglatchhandletowardsthefrontof
themoweruntilthelatchhooksclearthelocking
bar.
2.Raisetheplatform.Thegasspringwillprovide
assistance.
SecuringthePlatform
1.Lowertheplatformcarefully.Thegasspringwill
provideassistance.
2.Movethelockinglatchhandletowardsthefrontof
themowerastheplatformnearsthefullylowered
position.Thiswillensurethatthelatchhooksclear
thelockingbar.
3.Fullylowertheplatformandmovethelocking
handletowardstherearofthemoweruntilthelatch
hooksfullyengagethelockingbar.
G014422
Figure25
OperatorPresenceControl
Note:Theenginewillcutoutiftheoperatorleavesthe
seatwithoutengagingtheparkingbrake.
EngineStartLockout:Theenginecanonlybe
startedwhentheforward/reversetravelpedalisinthe
NEUTRALposition,thecuttingunitdriveswitchis
intheOFFpositionandtheparkingbrakeisengaged.
Whenthesecircumstancesaresatised,switchesare
activatedpermittingtheenginetobestarted.
EngineRunInterlock:Oncetheengineisstarted
theoperatormustbeseatedbeforetheparkingbrakeis
releasedfortheenginetocontinuetorun.
CuttingUnitDriveLockout:Thedrivetothecutting
unitsisonlypossiblewhentheoperatorisseated.If
theoperatorraisesofftheseatforaperiodofmore
thanonesecond,aswitchisactivatedandthedriveto
thecuttingunitisautomaticallydisengaged.Toengage
drivetothecuttingunit,theoperatormustreturnto
theseat,thenoperatethecuttingunitdriveswitchto
theOFFpositionbeforemovingitbacktotheON
position.Iftheoperatorrisesofftheseatforabrief
24
