High-LowSpeedControl
Theswitch(Figure10)allowsthespeedrangeto
increasefortransportingthemachine.T oswitch
betweentheHighandLowspeedranges,raisethe
cuttingunits,disengagethePTOandthecruise
control,putthetractionpedalintotheNEUTRAL
position,andmovethemachineataslowspeed.
Note:Thecuttingunitsdonotoperateand/orcannot
beloweredfromthetransportpositionwhenthe
switchisinthehighrange.
LiftSwitches
Theliftswitchesraiseandlowerthecuttingunits
(Figure10).Presstheswitchesforwardtolowerthe
cuttingunitsandrearwardtoraisethecuttingunits.
Whenstartingthemachine,withthecuttingunitsin
thedownposition,presstheliftswitchdowntoallow
thecuttingunitstooatandmow.
Note:Thecuttingunitsdonotlowerwhileinthe
high-speedrangeandtheydonotraiseorlowerifyou
areoutoftheseatwhiletheengineisrunning.Also,
thecuttingunitslowerwiththekeyintheONposition
andyouareintheseat.
Cruise-ControlSwitch
Thecruise-controlswitchlocksinthepedalposition
tomaintainthedesiredgroundspeed(Figure10).
Pressingtherearoftheswitchturnsoffthecruise
control,themiddlepositionoftheswitchenablesthe
cruise-controlfunction,andthefrontoftheswitchsets
thedesiredgroundspeed.
Note:Pressingeitherbrakepedalormovingthe
tractionpedalintothereverseposition,for1second,
alsodisengagesthepedalposition.
LightSwitch
Presstheloweredgeoftheswitch(Figure10)toturn
onthelights.Presstheupperedgeoftheswitchto
turnoffthelights.
PowerPoint
Usethepowerpoint(Figure11)topoweroptional
12Velectricalaccessories.
g036845
Figure11
1.Powerpoint2.Bagholder
BagHolder
Usethebagholderforstorage(Figure11).
SeatAdjustments
Seat-AdjustmentLever
Movetheseatadjustmentleveronthesideofthe
seatoutward,slidetheseattothedesiredposition,
andreleasethelevertolocktheseatintoposition
(Figure12).
g024916
Figure12
1.Weightgauge
4.Seat-backadjustment
lever
2.Weightadjustmentlever5.Armrestadjustmentknob
3.Seatadjustmentlever
