Toro 31201 - Positioning the Deluxe Seat

ChangingtheLumbarSupport
Thebackoftheseatcanbeadjustedtoprovideacustomized
lumbarsupportforyourlowerback.
Toadjustit,turntheknob,undertheleft-sidearmrest,in
eitherdirectiontoprovidethebestcomfort(Figure17).
PositioningtheDeluxeSeat
Figure19
1.Fore/Aft-adjustmentlever
4.Armrest-adjustmentknob
2.Weight-adjustmentlever5.Lumbar-support-adjustment
knob
3.Backrestlockinglever
ChangingtheWeightAdjustment
Youcanadjustthisseattoprovideasmoothandcomfortable
ride.
Important:Toadjusttheseatforthedriversweightthe
drivermustbeseatedandtheignitionkeymovedtothe
Onposition.
Theseatisadjustedforyourweightbypullingorpressingthe
weight-adjustmentlever(Figure19).
Yourweightisadjustedcorrectlywhenthearrowisinthe
middle,clearareaoftheviewingwindow.
Withinthisviewingarea,youcanadjusttheseattoaminimum
springmovement.
Whenyouhavereachedtheminimum/maximum-weight
adjustment,youcanhearitreachingtheupperorlowerend
stop.
Important:Topreventinjurytotheoperatorand/or
damagetothemachine,clickandadjustthesettingfor
yourweightandtheseatbeforeyouoperatethemachine.
Note:Toavoidcompressordamageduringweight
adjustment,donotoperatethecompressorlongerthan1
minute.
ChangingtheSeatPosition
Theseatcanmoveforwardandbackward.Positiontheseat
whereyouhavethebestcontrolofthemachineandaremost
comfortable.
1.Toadjust,liftthelevertounlocktheseat(Figure19).
2.Slidetheseattothedesiredpositionandreleaselever
tolockinposition.
3.Verifythattheseathaslockedintoplacebyattempting
tomoveitbackandforth.
Note:Donotoperatethelockingleverwhile
operatingthemachine.
ChangingtheLumbarSupport
Thelumbarsupportincreasesboththeseatingcomfortand
theperformanceofthedriver.
Thebackoftheseatcanbeadjustedtoprovideacustomized
lumbarsupportforyourlowerback.
Byturningtheadjustmentknobupwards,thecurvaturein
theupperpartofthebackrestcushioncanbeadjusted.By
turningtheknobdownward,youcanadjustthecurvaturein
thelowerpartofthebackrestcushion(Figure19).
0=Nocurvature
1=Maximumcurvatureatthetop
2=Maximumcurvatureatthebottom
AdjustingtheArmrests
Thearmrestscanbefoldedbackifrequiredandtheheight
individuallyadjusted.
Toadjustthearmrestsforheight,separatetheroundcap
(Figure19)fromthecover,loosenthehexagonnut(13mm)
behinditandadjustthearmreststothedesiredpositionand
tightenthenut.Replacethecapontothenut.
WARNING
Donotinstallthearmrestinthelowestpositionas
theseatbeltrollermightnotfunctionproperly.
ChangingtheArmrestAngle
Theangleofthearmrestscanbeadjustedforoperator
comfort.
Toadjusttheangleofthearmrests,turntheadjustmentknob
(Figure19).
Whenturningtheknobtotheoutside(+)thefrontpartof
thearmrestwillbelifted,whenturningtheknobtoinside(-)
itwillbelowered.
23
