Toro 31201 - Raising;Lowering the Seat; Pushing the Machine by Hand

ChangingtheBackrestPosition
Thebackoftheseatcanbeadjustedtoprovideamore
comfortableride.Positionthebackoftheseatwhereitis
mostcomfortable.
Pullupthelockinglevertoreleasethebackrestcatch(Figure
19).Whenreleasingthebackrestcatch,donotapplyloadto
thebackrestbypressingagainstit.
Byexertingpressureonoroffthefrontorrearoftheseatit
canbemovedtothedesiredposition.Releasethelocking
levertolockthebackrest.
Note:Thebackrestshouldnotbeabletomovetheinto
anotherpositionafterithasbeenlocked.
Raising/LoweringtheSeat
Toaccessthehydraulicandothersystemsundertheseat,you
needtounlatchtheseatandswingitforward.
1.Movetheseatlatch,locatedontheleftsideoftheseat,
rearwardtounlatchtheseatandpullforwardonthe
topoftheseat(Figure20).
Figure20
1.Seatlatch
2.Tolowertheseat,pullupontheseatlatchreleasebar
andlowertheseatintothelockedposition.
Figure21
1.Seatlatchreleasebar
PushingtheMachinebyHand
Ifthemachinestalls,runsoutoffuel,etc.youmayneedto
pushit.Todoso,yourstneedtoopenbothofthehydraulic
by-passvalves.
Important:Alwayspushthemachinebyhandand
neveralongdistance.Nevertowthemachinebecause
hydraulicdamagemayoccur.
PushingtheMachine
1.Disengagethepowertake-off(PTO),turntheignition
keytooffandapplytheparkingbrake.
2.Removethekeyfromtheignitionswitch.Both
by-passvalvesmustbeopened.
3.Lifttheseat.
4.Rotateeachby-passvalvecounterclockwise1turn
(Figure22).
Thisallowshydraulicuidtoby-passthepump
enablingthewheelstoturn.
Important:Donotrotatetheby-passvalvesmore
than1turn.Thispreventsvalvesfromcomingout
ofthebodyandcausinguidtorunout.
5.Disengagetheparkingbrakebeforepushing.
ChangingtoMachineOperation
Rotateeachby-passvalveclockwise1turnandhandtighten
them(torqueofapproximately8N-m[71in-lb])(Figure22).
Note:Donotovertightentheby-passvalves.
Themachinewillnotdriveunlessthebypassvalvesare
turnedin.
24
