Figure5
1.Rollbar3.Hairpincotterpin
2.Pin
4
CheckingtheTirePressure
NoPartsRequired
Procedure
Thetiresareoverinatedforshipping.Therefore,release
someoftheairtoreducethepressure.Thecorrectair
pressurefornon-cabmodelsis103kPa(15psi)inthefront
tiresand172kPa(25psi)inthereartires.Ifacabisinstalled
onthemachine,thefrontandreartiresshouldbeinatedto
172kPa(25psi).
5
CheckingtheFluidLevels
NoPartsRequired
Procedure
1.Checkthehydraulicuidlevelbeforestartingthe
engine,refertoCheckingtheHydraulicFluidLevelin
theMaintenanceSection.
2.Checktheengineoillevelbeforestartingtheengine,
refertoCheckingtheEngineOilLevelinthe
MaintenanceSection.
3.Checkthecoolingsystembeforestartingthe
engine;refertoCheckingtheCoolingSysteminthe
MaintenanceSection.
ProductOverview
Controls
Becomefamiliarwithallthecontrolsbeforeyoustartthe
engineandoperatethemachine.
TractionPedal
Thetractionpedal(Figure6)controlstheforwardandreverse
operation.Pressthetopofthepedaltomoveforwardandthe
bottomtomoverearward.Groundspeeddependsonhow
faryoupressthepedal.Fornoload,maximumgroundspeed,
fullypressthepedalwhilethethrottleisintheFastposition.
Tostop,reducefootpressureonthetractionpedalandallow
ittoreturntothecenterposition.
Note:Foremergencystops,presstherearofthetraction
pedal(reverse)tostopthemachinequickly.
Figure6
1.Parkingbrake4.Tractionpedal
2.Brakepedal
5.Speedlimiter
3.Tiltsteeringpedal
SpeedLimiter
Thespeedlimiterlever(Figure6)canbeippedforwardto
limitthetractionspeedwhileoperating.
BrakePedal
Thebrakepedalisusedinconjunctionwiththebrakepedal
latchtoengageanddisengagetheparkingbrake(Figure6)To
stopthemachine,releasethetractionpedalandallowitto
returntothecenterposition.Thebrakecanassistinstopping
inanemergencysituation.
