Toro 31222 - Adjusting the Height-Of-Cut

Height-of-Cut),andplacethepininthe15cm(6inch)
height-of-cutposition(Figure18).
EngagingthePowerTakeOff(PTO)
Thepowertakeoff(PTO)switchstartsandstopsthemower
bladesandsomepoweredattachments.
1.Iftheengineiscold,allowtheenginetowarmup5to
10minutesbeforeengagingthePTO.
2.Whileseatedintheseat,makesurethetractionpedalis
intheneutralpositionandtheengineisatfullthrottle.
3.PulluponthePTOswitchtoengageit(
Figure17).
Figure17
1.PTOswitch
DisengagingthePTO
Todisengage,pushthePTOswitchtotheoffposition.
AdjustingtheHeight-of-Cut
Theheight-of-cutisadjustedfrom2.5to15.8cm(1to
6inches)in6mm(1/4inch)incrementsbyrelocatingthe
stoppinintodifferentholelocations.
1.Withtheenginerunning,pushbackonthedecklift
switchuntilthemowerdeckisfullyraisedandrelease
theswitchimmediately(
Figure18).
2.Toadjust,rotatethestoppinuntilthenubonitlines
upwiththeslotsintheholesintheheight-of-cut
bracketandremoveit(Figure18).
3.Selectaholeintheheight-of-cutbracketcorresponding
totheheight-of-cutdesired,insertthepin,androtateit
downtolockitinplace(Figure18).
Note:Therearefourrowsofholepositions(Figure
18).Thetoprowgivesyoutheheightofcutlisted
abovethepin.Thesecondrowdowngivesyouthe
heightlistedplus6mm(1/4inch).Thethirdrow
downgivesyoutheheightlistedplus12mm(1/2inch).
Thebottomrowgivesyoutheheightlistedplus18mm
(3/4inch).Forthe15.8cm(6inch)positionthereis
onlyonehole,locatedinthesecondrow .Thisdoesnot
add6mm(1/4inch)tothe15.8cm(6inch)position.
Figure18
1.Stoppin
4.Adjusttheanti-scalprollersandskidsasrequired.
24
