ChangingtheWeightAdjustment
Theseatcanbeadjustedtoprovideasmoothandcomfortable
ride.
Important:Toadjusttheseatforthedriversweightthe
drivermustbeseatedandtheignitionkeymovedtothe
Onposition.
Theseatisadjustedforthedriver’sweightbypullingor
pressingtheweightadjustmentlever(Figure25).
Thedriver’sweightisadjustedcorrectlywhenthearrowisin
themiddleclearareaoftheviewingwindow.
Withinthisviewingarea,theseatcanbeadjustedtoa
minimumspringmovement.
Whentheminimum/maximumweightadjustmenthasbeen
reached,youcanhearitreachingtheupperorlowerendstop.
Important:Topreventinjurytotheoperatorand/or
damagetothemachine,thesettingforthedriver’s
weightandtheseatmustbecheckedandadjusted
beforethemachineisoperated.
Note:Toavoidcompressordamageduringweight
adjustment,thecompressormustbeoperatednolongerthan
1minute.
ChangingtheSeatPosition
Theseatcanmoveforwardandbackward.Positiontheseat
whereyouhavethebestcontrolofthemachineandaremost
comfortable.
1.Toadjust,liftthelevertounlocktheseat(Figure25).
2.Slidetheseattothedesiredpositionandreleaselever
tolockinposition.
3.Verifythattheseathaslockedintoplacebyattempting
tomoveitbackandforth.
Note:Donotoperatethelockingleverwhile
operatingthemachine.
ChangingtheLumbarSupport
Thelumbarsupportincreasesboththeseatingcomfortand
theperformanceofthedriver.
Thebackoftheseatcanbeadjustedtoprovideacustomized
lumbarsupportforyourlowerback.
Byturningtheadjustmentknobupwards,thecurvaturein
theupperpartofthebackrestcushioncanbeadjusted.By
turningtheknobdownwards,thecurvatureinthelowerpart
ofthebackrestcushioncanbeadjusted(
Figure25).
0=Nocurvature
1=Maximumcurvatureatthetop
2=Maximumcurvatureatthebottom
AdjustingtheArmrests
Thearmrestscanbefoldedbackifrequiredandtheheight
individuallyadjusted.
Toadjustthearmrestsforheight,separatetheroundcap
(Figure25)fromthecover,loosenthehexagonnut(13mm)
behinditandadjustthearmreststothedesiredpositionand
tightenthenut.Replacethecapontothenut.
WARNING
Donotinstallthearmrestinthelowestpositionas
theseatbeltrollermightnotfunctionproperly.
ChangingtheArmrestAngle
Theangleofthearmrestscanbeadjustedforoperator
comfort.
Toadjusttheangleofthearmrests,turntheadjustmentknob
(Figure25).
Whenturningtheknobtotheoutside(+)thefrontpartof
thearmrestwillbelifted,whenturningtheknobtoinside(-)
itwillbelowered.
ChangingtheBackrestPosition
Thebackoftheseatcanbeadjustedtoprovideamore
comfortableride.Positionthebackoftheseatwhereitis
mostcomfortable.
Pullupthelockinglevertoreleasethebackrestcatch(Figure
25).Whenreleasingthebackrestcatch,donotapplyloadto
thebackrestbypressingagainstit.
Byexertingpressureonoroffthefrontorrearoftheseatit
canbemovedtothedesiredposition.Releasethelocking
levertolockthebackrest.
Note:Thebackrestshouldnotbeabletomovetheinto
anotherpositionafterithasbeenlocked.
Raising/LoweringtheSeat
Toaccessthehydraulicandothersystemsundertheseat,you
needtounlatchtheseatandswingitforward.
1.Movetheseatlatch,locatedontheleftsideoftheseat,
rearwardtounlatchtheseatandpullforwardonthe
topoftheseat(Figure26).
