Toro 3280-D - Fixed Glass

Fixed Glass
Item #
Description
Qty.
JDP P/N
1
Windshield Glass 1 101454
n/a
Windshield Weatherstripping (16.04LF) 1 101460
2
Rear Window 1 101457
n/a
Rear Window Weatherstripping (11.09LF) 1 101463
3
Lower Right Window 1 101459
n/a
Lower Right Window Weatherstripping (7.43LF) 1 101465
4 Nut, Flange, 1/4", Macro-black 12 100223
5 Bolt, Step, 1/4" x 1 1/4", Macro-black 12 100003
6 Bushing, Neoprene, 5MM, Black 12 100382
7 Bushing, Neoprene, 8MM, Black 12 100381
16
