Toro 3280-D - Rops Mounting Assembly

ROPS Mounting Assembly
Item #
Description
Qty.
JDP P/N
1 Front Cab Bracket 1 101468
2 Rear Left Bracket 1 101469
3 Rear Right Bracket 1 101470
4 Bolt, Hex, 1/2" x 3", Gr. 8, YD 4 100121
5 Nut, Hex, Locking, 1/2", Gr. 8, YD 8 100116
6 Washer, Flat, Steel, 1/2" x 2 1/2", YD 4 100450
7 Isolator, Rubber, 1/2" x 2 1/2", Black 4 100448
8 Washer, Flat, Rubber, 1/2" x 2 1/2", YD 4 100449
9 Bolt, Hex, 1/2" x 1 1/2", Gr. 8, YD 4 100054
10 Bolt, Hex, 7/16" x 1 1/2", Gr. 8, YD 2 100886
11 Nut, Flange, 7/16", Gr. 8, YD 2 100763
