Toro 3280-D - Frame Parts

Frame Parts
Item #
Description
Qty.
JDP P/N
1 Striker Pin 1 100013
2 Striker Pin Nut 1 100014
3 Bolt, Flange, 1/4" x 1/2", YD 2 100278
4 Striker Plate 1 100012
5 Washer, Flat, 1/2", Gr. 8, YD 1 100431
6 Gas Shock 1 100365
7 Gas Shock Ball Stud 1 100366
8 Gas Shock Clip 2 100367
9 Bolt, Hex, 5/16" x 1 1/2", YD 2 100376
10 Latch Bushing 4 100033
11 Nut, Flange, 5/16", YD 2 100005
12 Window Arm Pin 1 100019
13 Nut, Flange, M10 x 1.5 1 100020
n/a Lift Hole Plug Buttons 2 100478
