RemovingtheSectionBypassHose

1.Removetheretainerthatsecuresthe90°barbedtting

ofthesectionbypasshosefortheboom-sectionvalves

fromthebulkheadttingatthebackofthesprayer

tank(Figure28).

Figure28

1.Retainer

3.Bulkheadtting(sprayer

tank)

2.90°barbedtting—section

bypasshose

(boom-sectionvalves)

2.Removethe90°barbedttingfromthebulkhead

tting(Figure28).

Note:RetaintheretainersforinstallationinInstalling

theSectionBypassHose(page37);younolongerneed

thebypasshosefortheboom-sectionvalves.

ReplacingtheValveElectrical

Connectors

Partsneededforthisprocedure:

Cableties

3-pinadapter

14-pinadapter

PreparingtheWireHarness

1.Atthebackofthemachine,removethe3tiewrapsthat

securetheconvolutedtubingandinline-fuseblockto

thewireharnessforthebranchlabeledRIGHTSPRAY

VALVEasshowninFigure29.

Figure29

1.DINconnectors

4.Inline-fuseblock

2.Label

5.Cableties

3.Convolutedtubing

2.Remove76mm(3inches)sectionofconvolutedtubing

asshowninFigure30.

Figure30

1.Removedsectionofconvolutedtube—76mm(3inches)

3.Positiontheconvolutedtubingtowardthemainbranch

ofthewireharnessasshowninFigure31.
