Toro 41188 Installation Instructions

1
PreparingtoInstalltheKit
NoPartsRequired
PreparingtheSprayerTankand
OptionalRinseTank
1.Parkthemachineonalevelsurface.
2.Engagetheparkingbrake.
3.Shutofftheengineandremovethekey.
Figure1
PreparingtheSprayerandOptional
RiseTankKit
1.Cleanthesprayer;refertoCleaningtheSprayerinthe
Operator’sManualforthemachine.
Important:Youmustcompletelyemptythe
sprayertankbeforeinstallingtheValveConversion
Kit.
2.Formachineswiththeoptionaltank-rinsekit,
performthefollowing:Pumpthewaterfromthe
rinsetankintothesprayertank;refertoOperating
theRinseKitintheInstallationInstructionsforthe
Tank-RinseKit.
3.Drainthewaterfromthesprayertank(Figure2);refer
toCleaningtheSprayerintheOperator’sManualforthe
machine.
Figure2
1.Valvebracket3.Drainvalve
2.Mountbolt
