HourmeterInstallation(continued)
g346221
Figure82
3.InstalltheRHsidepodtotheRHconsole.Installthe4(1/4-20inch)torx
screwssecuringtheRHsidepodtotheRHconsole.
4.Connectthebatterybyinstallingthepositivecablerst,thenthenegative
cabletothebattery.
HourmeterTest
WiththeignitionswitchintheRUNpositionandthePTOswitchclosed(ON),
verifybatteryvoltageandgroundtothehourmeter.
g336418
Figure83
LeftandRightNeutralSwitchReplacement
LeftandRightNeutralSwitchRemoval
1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stopthe
engine,waitforallmovingpartstostopandremovethekey.Engagethe
parkingbrake.
2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
Electrical:ServiceandRepairs
Page8–6
4000SeriesZMASTER®ServiceManual
3442-427RevA
