IgnitionSwitchTest(continued)

4.Usingadigitalmulti-metersettotheOHMorContinuitysetting,verifythat

NOcontinuityexistsbetweentheterminalsnotlistedforeachswitchposition.

Position

Circuit“Make”

OFF

None

RUNB+R+I+A

STARTB+R+I+S

HourmeterReplacement

HourmeterRemoval

1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stopthe

engine,waitforallmovingpartstostopandremovethekey.Engagethe

parkingbrake.

2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive

cablefromthebattery.

3.Removethe4(1/4-20inch)torxscrewssecuringtheRHsidepodtotheRH

console.RemovetheRHsidepodfromtheRHconsole.

4.Disconnectthewiringharnessfromthehourmeter.

g346221

Figure81

5.Pinchtogetherthe2tabsonthehourmeter.Pushingfromthebottomside

up,removethehourmeterfromtheRHsidepod.

HourmeterInstallation

1.InstallthehourmeterintotheRHsidepod.

2.Connectthewiringharnessfromthehourmeter.

4000SeriesZMASTER®ServiceManual

Page8–5

Electrical:ServiceandRepairs

3442-427RevA
