SeatInstallation(continued)

g346224

Figure38

6.Installthe2(5/16inch)torxscrewssecuringtherearseatpantothechassis.

g348057

Figure39

7.Connectthebatterybyinstallingthepositivecablerst,thenthenegative

cabletothebattery.

MYRIDE®Replacement

MYRIDE®Removal

1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stopthe

engine,waitforallmovingpartstostopandremovethekey.Engagethe

parkingbrake.

2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive

cablefromthebattery.

3.MovetheMYRIDEspringstothe#5position.

4.Removethe4(5/16inch)locknutsandcarriageboltssecuringtherearseat

pantotheMYRIDEplatform.

5.Withassistance,tiptheseatforwardanddisconnecttheseatswitch.

Chassis:ServiceandRepairs

Page5–20

4000SeriesZMASTER®ServiceManual

3442-427RevA
