ROPS(RollOverProtectionSystem)Replacement

ROPS(RollOverProtectionSystem)Removal

1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stopthe

engine,waitforallmovingpartstostopandremovethekey.Engagethe

parkingbrake.

2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive

cablefromthebattery.

3.Removethefueltank.FuelT ankReplacement(page5–24)

4.RemovethehairpinsandROPSfoldpins.

5.LowertheupperROPSassemblytothefull-downposition.

g346262

Figure47

6.RemovetheLHshoulderboltsecuringtheupperROPSassemblytothe

lowerROPSassembly.

7.WhilesupportingtheupperROPSassembly,removetheRHshoulderbolt

securingtheupperROPSassemblytothelowerROPSassembly.

Note:MayneedassistancetosupporttheupperROPSassembly.

CAUTION

UpperROPSassemblyisheavy,assistanceorsupportisneededfor

removal.Personalinjuryordamagemayoccur.

8.LifttheupperROPSassemblyawayfromthemachine.

9.Removethe4(½inch,2perside)boltsandlocknutssecuringthelower

tubestothechassis.

Chassis:ServiceandRepairs

Page5–26

4000SeriesZMASTER®ServiceManual

3442-427RevA
