ThrottleCableAssemblyReplacement
ThrottleCableAssemblyUnitRemoval
1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stopthe
engine,waitforallmovingpartstostopandremovethekey.Engagethe
parkingbrake.
2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
3.Removethe4(1/4-20inch)torxscrewssecuringtheRHsidepodtotheRH
console.RemovetheRHsidepodfromtheRHconsole.
Note:Inimagebelow,3screwsareshown.
g346220
Figure30
4.Unscrewthethrottlecontrolknobfromthethrottlecontrol.
5.Fromthebottomsideofthethrottlecontrol,removethe2(10-24inch)lock
nutssecuringthethrottlecontroltotheRHconsole.
6.Disconnectthethrottlecable.
ThrottleCableAssemblyEngineRemoval
Notethepositionofthethrottleclampontheengineplate.
1.Removethecableclampscrewsecuringthecabletotheengineplate.
Removetheclampfromtheengineplate.
2.Disconnectthethrottlecable.
ThrottleCableAssemblyEngineInstallation
1.Connectthethrottlecable.
2.Installtheclamptotheengineplate.Installthecableclampscrewsecuring
thecabletotheengineplate.
ThrottleCableAssemblyUnitInstallation
1.Connectthethrottlecable.
2.Fromthebottomsideofthethrottlecontrol,installthe2(10-24inch)lock
nutssecuringthethrottlecontroltotheRHconsole.
3.Screwthethrottlecontrolknobtothethrottlecontrol.
4.InstalltheRHsidepodtotheRHconsole.Installthe4(1/4-20inch)torx
screwssecuringtheRHsidepodtotheRHconsole.
4000SeriesZMASTER®ServiceManual
Page5–15
Chassis:ServiceandRepairs
3442-427RevA
