Toro 74096 - Safety-Interlock System; Understanding the Safety-Interlock System

g225804
Figure8
1.Upperpartoftherollbar4.Rotatetheknobout90°
toholditintheunlatched
position.
2.Knobinthelatched
position
5.Knobintheunlatched
position
3.Pulltheknobtounlatch.
RaisingtheRollBar
Important:Alwaysusetheseatbeltwiththeroll
barintheraisedposition.
1.Raisetherollbartotheoperatingpositionand
rotatetheknobsuntiltheymovepartiallyinto
thegrooves(Figure9).
2.Raisetherollbartothefulluprightpositionwhile
pushingontheupperrollbarsothatthepins
snapintopositionwhentheholesalignwiththe
pins(Figure9).
3.Pushontherollbarandensurethatbothpins
areengaged(Figure9).
g008619
Figure9
1.Engaged2.Partiallyengaged—donot
operatethemachinewith
theROPSinthisposition.
UsingtheSafety-Interlock
System
WARNING
Ifthesafety-interlockswitchesare
disconnectedordamaged,themachinecould
operateunexpectedly,causingpersonal
injury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlock
switchesdailyandreplaceanydamaged
switchesbeforeoperatingthemachine.
Understandingthe
Safety-InterlockSystem
Thesafety-interlocksystemisdesignedtopreventthe
enginefromstartingunless:
•Theparkingbrakeisengaged.
•Theblade-controlswitch(PTO)isdisengaged.
•Themotion-controlleversareintheNEUTRAL-LOCK
position.
Thesafety-interlocksystemalsoisdesignedtoshut
offtheenginewhenthemotion-controlleversare
movedfromtheNEUTRAL-LOCKpositionwiththe
parkingbrakeengagedorifyourisefromtheseat
whenthePTOisengaged.
TheHorizonDisplayMonitorhassymbolstonotify
theuserwhentheinterlockcomponentisinthe
correctposition.Whenthecomponentisinthecorrect
position,thecorrespondingsymboldisplaysonthe
monitor.
g230650
Figure10
1.Symbolsdisplayonthemonitorwhentheinterlock
componentsareinthecorrectposition.
18
