Toro 74096 - Adjusting the Tracking; Tracking Adjustment Procedure

AdjustingtheTracking
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andengagetheparking
brake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.MovethethrottlemidwaybetweenFASTand
Slow.
4.Movebothmotion-controlleversalltheway
forwarduntiltheybothhitthestopsintheT-slot.
5.Checkwhichwaythemachinetracks.
•Ifittrackstotheright,loosentheboltsand
adjusttheleftstopplaterearwardonthe
leftT-slotuntilthemachinetracksstraight
(Figure50).
•Ifittrackstotheleft,loosentheboltsand
adjusttherightstopplaterearwardonthe
rightT-slotuntilthemachinetracksstraight
(Figure50).
6.Tightenthestopplate(Figure50).
g254284
Figure50
1.Controllever3.Stopplate
2.Bolt
7.Aligntheleversinthefront-to-rearpositionby
bringingtheleverstogethertotheNEUTRAL
position,andslidethemuntiltheyarealigned,
thentightenthebolts(Figure51).
g009195
Figure51
8.Ifalignmentisneeded,loosenthe2
motion-controllevermountingboltsonthe
misalignedside(Figure52).
g254283
Figure52
9.Movemotion-controllevertomeettheopposite
side.
10.Tightenthe2motion-controllevermounting
bolts(Figure52).
