ServicingtheFuses
Theelectricalsystemisprotectedbyfuses.Itrequires
nomaintenance,however,ifafuseblowscheck
component/circuitformalfunctionorshort.
1.Unlatchtheenginehoodandraisetheengine
hoodtogainaccesstothefuseblock.
2.T oreplacethefuses,pulloutonthefuseto
removeit.
3.Installanewfuse(Figure48).
g235614
Figure48
1.Accessory(15A)3.Main(25A)
2.Chassis(15A)4.Powerpoint(15A)
DriveSystem
Maintenance
ReleasingtheDriveWheel
ReleaseValves
Usethedrivewheelreleasevalvestoreleasethe
hydrostaticdrivesystem,whichallowsyoutopushthe
machinewithouttherunningtheengine.
Rotateeachbypassvalvecounterclockwise1turnto
release;rotateeachbypassvalveclockwisetoreset
system(Figure49).
Important:Donotovertighten.Donottowthe
machine.
g004644
Figure49
1.Rightbypassvalve
2.Leftbypassvalve
44
